Low Cost High Precision CNC Cutting Machine

Name: Low Cost High Precision CNC Cutting Machine
Brand: SUZHOU BMG PRECISION MACHINERY CO., LTD
Price: 58000 INR
Availability: InStock

Price 58000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Low Cost High Precision CNC Cutting Machine Specification

Product Type
Low Cost High Precision CNC Cutting Machine

General Use
Industrial

Material
Metal

Type
Automatic CNC Machine

Capacity
Up to 200 mm thickness (material dependent)

Weight (kg)
Approx. 1800 kg

Computerized
Yes

Automatic
Yes

PLC Control
Yes

Bar Feeder
No

Power Source
Electric

Power Consumption
4-8 kW (depending on configuration)

Rigidity
High Rigidity Structure

Voltage
380V / 50Hz

Motor
High Precision Servo Motor

Table Size
600 x 900 mm (customizable)

Spindle Speed
0-12000 RPM

Axial Choice
3/4/5 axis (optional)

Dimension (L*W*H)
2400 x 2000 x 1800 mm

Feature
High Precision, Low Cost, User-Friendly Interface, Stable Performance

Color
Silver with Green Accents

Minimum Order Quantity
1 Unit

Cooling System
Water Cooled / Air Cooled (Optional)

Software Compatibility
G-code, DXF, and other standard CAD formats

Drive System
Ball Screw Drive

Safety Feature
Emergency Stop, Full Enclosure, Interlock Switches

Cutting Accuracy
0.01 mm

Display
Touchscreen HMI

Noise Level
75 dB

Lubrication System
Automatic Central Lubrication

Service Support
Onsite Installation and Training Available

Work Environment
Temperature 0-40C, Humidity 85%

Low Cost High Precision CNC Cutting Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Paypal, Telegraphic Transfer (T/T)

Delivery Time
2-3 Week

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Low Cost High Precision CNC Cutting Machine About

By using the advanced infrastructure unit, we are manufacturing, exporting and supplying the qualitative range of the Low Cost High Precision CNC Cutting Machine. Our products are widely used in various industrial applications and highly recommended for its precise design, smooth operation, flawless functioning, rigid construction, fine finishing and durability. These are prepared at our premises, under the guidelines of our talented engineers, by using the premium quality raw materials. Further, we are providing the range of the Low Cost High Precision CNC Cutting Machine in different specifications and at competitive rates.

Cutting-Edge Precision and Consistency

Benefit from stable, repeatable results thanks to advanced ball screw drive technology and a high-rigidity frame. The machine sustains accuracy of 0.01 mm, ensuring fine, detailed cuts in industrial metal-working tasks. From prototypes to batch production, its robust design maintains high performance in demanding environments.

Flexible Operation for Varied Applications

Adapt to changing requirements with customizable options-choose from water-cooled or air-cooled systems and select 3, 4, or 5 axes to suit your production needs. The machine works with multiple CAD/CAM formats, making integration seamless across different workflow setups for maximum productivity.

Safety and Automation Built-In

A full enclosure, emergency stop, interlock switches, and an automatic central lubrication system help maintain a safe and reliable workspace. Operators interact through an intuitive touchscreen HMI, streamlining control and minimizing downtime during operation or maintenance tasks.

FAQ's of Low Cost High Precision CNC Cutting Machine:

Q: How does the CNC machine achieve such high cutting accuracy?

A: The machine utilizes a high-rigidity structure coupled with a precision ball screw drive and high precision servo motor, enabling cutting accuracy up to 0.01 mm. This advanced construction reduces vibration and ensures smooth, consistent motion during cutting operations.

Q: What types of materials can be processed with this CNC machine?

A: This CNC cutting machine is primarily designed for metal materials, accommodating up to 200 mm thickness (depending on the material's properties). Its high-power spindle and stable platform make it suitable for a wide range of industrial cutting applications.

Q: When is onsite installation and training available for new users?

A: Onsite installation and training are available with every machine purchase. Once your order is confirmed and the machine is delivered, our technical team schedules a visit to install the equipment and provide comprehensive operational training to ensure efficient and safe use.

Q: Where can the CNC cutting machine be installed and operated?

A: The machine is engineered for use in industrial environments with temperatures ranging from 0C to 40C and humidity up to 85%. It requires a stable 380V/50Hz electric supply and an allocated floor space to fit its 2400 x 2000 x 1800 mm dimensions.

Q: What is the process for integrating this machine with existing CAD/CAM systems?

A: Integration is straightforward, as the machine supports G-code, DXF, and other standard CAD formats. Simply prepare your cutting files in your preferred design software, then upload them via the touchscreen HMI for seamless operation.

Q: How does the automatic central lubrication system benefit users?

A: The automatic central lubrication system ensures that all critical motion parts receive consistent lubrication, reducing maintenance requirements, preventing premature wear, and extending the machine's operational life with minimal user intervention.

Q: What are the benefits of choosing this CNC cutting machine for my facility?

A: This machine offers a compelling combination of high precision, low operational cost, user-friendly controls, and robust safety features. With flexible configuration options and onsite support, it delivers stable, accurate, and productive performance for diverse industrial metal cutting needs.
